Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints

Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints

  • Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints
  • Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints
  • Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints
Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints
Product Details:
Place of Origin: Changzhou,Jiangsu, China
Brand Name: Auspicious plastic
Certification: MSDS
Model Number: 6/8/10/15/20/25mm,etc
Payment & Shipping Terms:
Minimum Order Quantity: 1000000meters
Price: Negotiable
Packaging Details: plastic bag or carton
Delivery Time: 7 working days
Payment Terms: T/T
Supply Ability: 10000000000000meters per year
Contact Now
Detailed Product Description
Material: Polyethylene Foam Color: White, Gray, Black, Etc
Feature: Environmental Friendly Usage: Construction Use
Place: Tiling, Flooring, Decorative Wall Paneling, Window Sealing, Stonework And Counter Steps Function: Save Time And Cost
Weight: Light Size: 6mm, 8mm, 10mm ,etc
Origin: China Length: Customize
High Light:

pe foam backer rod

,

foam caulking cord



Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints



Backer Rod is an extruded, round, closed cell polyethylene foam designed to effectively fill the gaps between logs prior to the application of log caulking. Backer Rod is flexible and compressible; it conforms to the irregularities in the log surface.






Contact us via monica@xl-product.com
  86-13801508970



Features:

  • Round closed cell polyethylene rod / rope allows easier installation without staples, nails or glue
  • Flexible and compressible
  • Conforms to the irregularities in the log surface
  • Under normal use, will not cause out gassing or blistering
  • Will not absorb water
  • Heat and cold stable
  • Seals off air leaks by providing extra insulation



Installation Guides
Standard practice for closed-cell backer rod is that with joints less than 3/4 inch (19mm) wide, the backer rod diameter should be 1/8 inch (3mm) larger than the joint width, and with joints 3/4 inch (19mm) or larger, the backer rod diameter should be around 25%-30% larger than the joint width.





The following table provides appropriate backer rod sizes for various building joint widths.



Joint Width
Inches (Millimeters)
Closed-Cell Backer Rod Diameter
Inches (Millimeters)
3/16 (5) 1/4 (8)
1/4 (6) 3/8 (9)
3/8 (10) 1/2 (13)
1/2 (13) 5/8 (16)
9/16 (14) 3/4 (17)
5/8 (16) 3/4 (19)
11/16 (17) 7/8 (20)
3/4 (19) 1 (25)
7/8 (22) 1-1/8 (29)
1 (25) 1-3/8 (33)
1-1/8 (29) 1-1/2 (39)
1-1/4 (32) 1-5/8 (43)
1-3/8 (35) 1-7/8 (47)
1-1/2 (38) 2 (51)
1-5/8 (41) 2-1/8 (55)
1-3/4 (44) 2-3/8 (59)
1-7/8 (48) 2-1/2 (64)
2 (51) 2-5/8 (68)
2-1/4 (57) 2-7/8 (74)
2-1/2 (64) 3-1/4 (83)
2-3/4 (70) 3-5/8 (91)
3 (76) 3-7/8 (98)
3-1/2 (89) 4-1/2 (115)
4 (102) 5-1/8 (132)





Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints 1



Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints 2
