| Place of Origin: | Changzhou,Jiangsu, China |
| Brand Name: | Auspicious plastic |
| Certification: | MSDS |
| Model Number: | 6/8/10/15/20/25mm,etc |
| Minimum Order Quantity: | 1000000meters |
|---|---|
| Price: | Negotiable |
| Packaging Details: | plastic bag or carton |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 10000000000000meters per year |
| Material: | Polyethylene Foam | Color: | White, Gray, Black, Etc |
|---|---|---|---|
| Feature: | Environmental Friendly | Usage: | Construction Use |
| Place: | Tiling, Flooring, Decorative Wall Paneling, Window Sealing, Stonework And Counter Steps | Function: | Save Time And Cost |
| Weight: | Light | Size: | 6mm, 8mm, 10mm ,etc |
| Origin: | China | Length: | Customize |
| High Light: | Sealant Joint caulk filler rope,Polyethylene caulk filler rope,customize caulking backer rod |
||
Sealant Joint Backing Materials PE Foam Backer Rod Between Concrete Joints
Backer Rod is an extruded, round, closed cell polyethylene foam designed to effectively fill the gaps between logs prior to the application of log caulking. Backer Rod is flexible and compressible; it conforms to the irregularities in the log surface.
| Contact us via | monica@xl-product.com |
| 86-13801508970 |
Features:
Installation Guides
Standard practice for closed-cell backer rod is that with joints less than 3/4 inch (19mm) wide, the backer rod diameter should be 1/8 inch (3mm) larger than the joint width, and with joints 3/4 inch (19mm) or larger, the backer rod diameter should be around 25%-30% larger than the joint width.
The following table provides appropriate backer rod sizes for various building joint widths.
| Joint Width Inches (Millimeters) |
Closed-Cell Backer Rod Diameter Inches (Millimeters) |
|---|---|
| 3/16 (5) | 1/4 (8) |
| 1/4 (6) | 3/8 (9) |
| 3/8 (10) | 1/2 (13) |
| 1/2 (13) | 5/8 (16) |
| 9/16 (14) | 3/4 (17) |
| 5/8 (16) | 3/4 (19) |
| 11/16 (17) | 7/8 (20) |
| 3/4 (19) | 1 (25) |
| 7/8 (22) | 1-1/8 (29) |
| 1 (25) | 1-3/8 (33) |
| 1-1/8 (29) | 1-1/2 (39) |
| 1-1/4 (32) | 1-5/8 (43) |
| 1-3/8 (35) | 1-7/8 (47) |
| 1-1/2 (38) | 2 (51) |
| 1-5/8 (41) | 2-1/8 (55) |
| 1-3/4 (44) | 2-3/8 (59) |
| 1-7/8 (48) | 2-1/2 (64) |
| 2 (51) | 2-5/8 (68) |
| 2-1/4 (57) | 2-7/8 (74) |
| 2-1/2 (64) | 3-1/4 (83) |
| 2-3/4 (70) | 3-5/8 (91) |
| 3 (76) | 3-7/8 (98) |
| 3-1/2 (89) | 4-1/2 (115) |
| 4 (102) | 5-1/8 (132) |
